This Cold Cutting Bag-Making Machine has optical tracking, computer fixed-length, automatic counting, pneumatic punching, to the number of alarm. Suitable for PE, OPP, BOPP and other plastic materials, automatic heat sealing and cutting the production of knitting, clothing, food, stationery packaging, is the alternative to imported products of advanced equipment bag.

Product Details
cutting width 650mm
cutting length materials, 35-1000 mm
Overall dimensions 2650 × 1400 × 1350mm
cutting accuracy of ± 1mm maximum
cutting speed of 50-250 times / min
basic information Product name origin of computer control heat sealing and cutting machine
Model GFQ Ryan -700 Type

Cold Cutting Bag-Making Machine Product Description：
This machine has optical tracking, computer fixed-length, automatic counting, pneumatic punching, to the number of alarm. Suitable for PE, OPP, BOPP and other plastic materials, automatic heat sealing and cutting the production of knitting, clothing, food, stationery packaging, is the alternative to imported products of advanced equipment bag. :: Details Uses: For low density polyethylene (LDPE), high density polyethylene (HDPE) film sealing qualities of bags, color bags. Widely used in food packaging, clothing packaging, industrial, electrical product packaging.

Features: 1 bag automatic counting, automatic alarm. 2, the photoelectric eye tracking is correct, the error bag machine automatically shut down more than four hours. 3, the bag length from the button control.

Cold Cutting Bag-Making Machine Main technical parameters:
Model GFQ-500 type GFQ-700 type
Maximum sealing width 500mm 650mm
Sealing length 80000min 1000min
Sealing and Cutting Thickness 0.004-0.10mm 0.004-0.10mm
Error of ± 1mm ± 1mm
length Speed bag 40-120pcs/min 40-120pcs/min
Main motor power 1.1kw 1.5kw
Heating power 1.2kw 1.5kw Total power 2.5kw 3.2kw
Weight 700kg 820kg Dimensions (L ×) W × H) 2650×1200×1350mm 2650×1400×1350mm
