500/1000 type OPP bag making machine (computer bag making machine) Details：
RFQ series is my computer bag making machine plastic packaging company for the needs of the market, research
System developed a keen edge sealing bag equipment, supporting the use of the same film can be folded on the OPP, PP, PE, shrink film of plastic material for sealing and cutting bag. Models based on its configuration and function of different sub-
As Class II (see below). The products are widely used in clothing, stationery, hardware and other products Packaging.
The machine set machine, electricity, gas as a whole, the use of advanced single-chip microcomputer as the master, together with the step
Type fixed-length, optical scan tracking, temperature controlled, air drilling and other industrial equipment to the production of packages
Packaged product size precision, sealed solid line, tangent and beautiful that you can be assured of quality equipment bag.
When you order, please read the menu below to choose the model you need.

OPP bag making machine Technical parameters：Basic instructions RFQ350/800 PC computer eagerly looking machine RFQ500/800 Multifunctional Machine
Basic specifications for bag material folded film forming OPP, PE, PP, folded shrink film forming OPP, Jane profiles PE, PP, shrink film
Effective width of 500,700 mm 500,700 mm bag
The effective length of the bag 50 ~ 1000mm 500 ~ 1000mm
Accuracy of ± 0.5mm ± 0.5mm Bag
Mechanical speed 200pcs/min 200pcs/min
Power supply AC 220V or AC380V AC single-phase single-phase 220V or AC380V
Machine spare power 4kw 5kw
Frame in the form of unwinding duplex cone solid fan-style duplex cone solid fan-type (LPC correction discharge device)
OPP bag making machine Coil diameter Ф500mm Ф500mm
Tension way manual manual mechanical mechanical friction Friction (optional magnetic particle brake)
Feeding Mode DC motor speed control, arm type feeding DC motor speed control, arm type feeding
Mechanical power main motor 0.75kw 0.75kw inverter motor variable frequency motor
Transmission pulley
Fixed length correctly predicted a long way to pull the stepper motor system, computer-controlled stepper motor and computer control (optional servo motor)
Optical inspection mark switch Photoelectric Switch Photoelectric mark
Seal bag features the form of sliced, sliced fancy point, the point of fancy
Tube-type materials can be made open edge to open edge, insert the end of M, envelope-style
Article is not on the stickers, punch-line stickers on the article, Ф6mm single stickers on the aircraft punched holes article, Ф6mm aircraft Hole Punch
Temperature 0 ~ 400 ℃ cutter way of digital temperature controller 0 ~ 400 ℃ digital temperature controller
Roller compacted 0 ~ 300 ℃ temperature control pointer
Optional features to import or distribution control electrical components imported from Taiwan or Taiwan
